AutoCAD DXF

GIS File Name

CAMB3D_Tile_CAD.dxf

Format

dxf

Description

The City of Cambridge, Massachusetts, Geographic Information System (GIS) City-Wide 3D project provides a detailed three-dimensional model including the terrain, groundplan and buildings of the city. The city-wide model has been cut into one-kilometer squares for exchange with 3D design tools. Each file associated with the tiled 3D model is named with the prefix CAMB3D_ then the tile name, e.g. G5_, then the name of the dataset.

The Tiled CAD datasets provides exports of several layers from the Cambridge GIS Data Dictionary.

Purpose

These tiles are made available for users who want to use design tools to re-mix basemaps or to develop schemes involving altered groundplan features and terrain

Download Layer Data

View 3D Data Download Map

Sources

These tiled terrain layers were made with the following city-wide layers available for download from the City of Cambridge GIS. Except for the parcel boundaries, these data sets data were developed photogrammetrically by Infotec USA using aerial photography from April 2010.

3D Basemap Sources:
ASSESSING_ParcelsFY2016 BASEMAP_Buildings BASEMAP_Cemeteries
BASEMAP_Driveways BASEMAP_Roads BASEMAP_Driveways
BASEMAP_ParkingLots BASEMAP_Plazas BASEMAP_Sidewalks
BASEMAP_Stairs BASEMAP_PrivateWalkways BASEMAP_PublicFootpaths
BASEMAP_ImperviousOther BASEMAP_SwimmingPools BASEMAP_Vegetation
BASEMAP_Walls RECREATION_OpenSpace RECREATION_SportsAreas
HYDRO_WaterBodies HYDRO_Wetlands TRANS_Rail
TRANS_Centerlines TRAFFIC_PavementMarkings ELEVATION_Contours (1 Foot)
ELEVATION_DTM_Breaklines ELEVATION_DTM_Points

Background in areas beyond the city limits is covered with roads, openspace and 2003 building data from massGIS.

Coordinate System

Massachusetts State Plane, Mainland Zone, NAD83
